Moğolistan'a Satılık 1 Takım 5t-S16m-H6m Tek Kirişli Portal Vinç

Ayrıntılı özellikler:

• Kapasite: 5 ton
• Span: 16 meter
• Lifting Height: 6 meter
• Lifting Speed: 0.8/8 m/min
• Trolley traversing speed: 2 to 20 m/min
• Crane traveling speed: 2 to 20 m/min
• Working group: M5

We got the inquiry of this tek kirişli gezer vinç from our new client in Mongolia. As there are some special conditions at the work site, our client named a few requirements.

1. The hoist is low headroom type to reduce the total height of the crane. The main beam is square box structure using material Q345.
2. The crane is equipped with an anemometer to deal with local windy weather, and is also equipped with sound and light alarms.The electrical cabinet can be heated to cope with cold weather, and a timer and 220v socket were added in the electrical cabinet.
3. Electrical components brand designated as Schneider, which is relatively easy to obtain in different countries and regions.
4. Control methods are pendant control plus wireless remote control to allow easy operation.
5. As there was already rail tracks and the rail type is P43, we designed the crane traveling mechanism according to this rail type.
6. Our client need precision operations some time, so the trolley traversing and crane traveling drives were VFD motors thus allowing for variable speed.

Since Mongolia is a landlocked country, we could not ship our goods by sea. Truck transportation was adopted for the the delivery from our factory to the client. The delivery was divided into two parts. Part one is from our factory at Xinxiang, Henan, to Erenhot, Inner Mongolia, where the customs clearance was went through. The second part is from Erenhot to our client’s door.

Truck transportation is more expensive way to ship goods, so in order to help our client reduce possible future cost of buying and shipping wear parts, we provided several spare parts to the client for free, such as a set of hoist wire rope and a brake ring.

The crane arrived at the house of our client and was installed immediately. Now the crane is working smoothly at the work site.

Özel gereksinimleri olan bir portal vincine ihtiyacınız varsa, lütfen bize bildirmekten çekinmeyin. Renk, logo ve benzeri görünüm dahil olmak üzere özelleştirilmiş hizmet sunuyoruz. Lütfen bizi bilgilendirin:

1. Kaldırma kapasitesi
2. Açıklık
3. Ağırlık kaldırmak
4. Özel gereksinimler.
